Allen-Bradley PLC programming services: PLC-5 through ControlLogix.

Studio 5000, RSLogix, FactoryTalk View, PowerFlex, and Kinetix — including the racks that outlived their spare-parts list.

Request a quote
Line down? (877) 790-4697 24/7, subject to personnel availability
Controllers
PLC-5 to ControlLogix
Software
RSLogix, Studio 5000
Drives
PowerFlex, Kinetix

Illustrative model

  1. Studio 5000The laptop online with the ControlLogix
  2. RunXIC: Run is on, so the rung stays true
  3. FaultXIO: Fault is off, so the rung stays true
  4. MotorOTE: the rung is true, so Motor turns on

What we program

What we program
AreaWhat we program
ControllersPLC-5, SLC 500, ControlLogix, CompactLogix, GuardLogix
SoftwareRSLogix 5, RSLogix 500, RSLogix 5000, Studio 5000, FactoryTalk View
NetworksEtherNet/IP, DeviceNet, DH+, TCP/IP
DrivesPowerFlex, Kinetix, SEW and other third-party drives

FactoryTalk View ME and SE

FactoryTalk View ME, the software for PanelView Plus terminals, and FactoryTalk View SE. During a PLC-5 or SLC 500 migration, PanelView Standard and older HMIs move to FactoryTalk View ME or SE.

Field note: when to stop using ME.

ME
PanelView Plus terminals
SE
FactoryTalk View SE stations

PanelView terminals

Terminals
PanelView Standard, PanelView Plus 6 and 7, PanelView 5000
Software
PanelBuilder32, FactoryTalk View ME and SE, View Designer
Files to send
The application archive (.APA); for ME, the runtime (.MER) too

Studio 5000 Logix Designer

ControlLogix and CompactLogix in RSLogix 5000 and Studio 5000: motion, safety, and standard Logix.

ControlLogix (1756)
Chassis-based Logix controller, including 5580
CompactLogix (1769, 5069)
5370, 5380 and 5480 controllers
GuardLogix
Safety controllers (ControlLogix and CompactLogix)
Software
RSLogix 5000 (v20 and earlier), Studio 5000 Logix Designer (v21 and later)

Typical jobs

PLC-5

Obsolete, still holding lines together. We support it — and we will map an upgrade path when the rack is one failed 1771 card away from a long outage.

SLC 500

RSLogix 500 and FactoryTalk View Studio. Edits to the program you have, or a new one from a blank project.

ControlLogix / CompactLogix

RSLogix 5000 and Studio 5000. Motion, safety, and standard Logix. FactoryTalk View SE and ME on the HMI side.

PowerFlex, Kinetix, and networks

Drive install and optimize, SEW and other third-party drives, EtherNet/IP, TCP/IP, DeviceNet, and I/O.

Where PLC-5 and SLC 500 stand

Plants we’ve supported

All plants supported
  • BMW Plant 10Automotive, Greer, SC
  • Mercedes-Benz U.S. InternationalAutomotive, Vance, AL
  • TeslaElectric vehicle production
  • SpaceXAerospace
  • Robert Bosch LLCAutomotive, Charleston, SC
  • thyssenkrupp TKAE / TKABAutomation engineering, Body solutions
  • Our next value-added customerYour plant

Straight answers.

Are PLC-5 and SLC 500 still supported?

Yes. We still speak PLC-5 and SLC 500, RSLogix 500 included: edits to the program you have, or a new one from a blank project.

Can an upgrade off PLC-5 or SLC 500 be planned?

Yes. We support the rack you have today and map an upgrade path off it while it still runs, instead of after one failed 1771 card turns into a long outage. How it runs: PLC-5 to ControlLogix and SLC 500 to CompactLogix.

Which Rockwell software do you work in?

RSLogix 500, RSLogix 5000, and Studio 5000 for the controllers, including motion, safety, and standard Logix, and FactoryTalk View SE and ME for the HMI.

Are PowerFlex and Kinetix drives set up on site?

Yes. Drive install and optimization for PowerFlex and Kinetix, SEW and other third-party drives, plus EtherNet/IP, DeviceNet, TCP/IP, and I/O.

Are PanelView and FactoryTalk View HMIs part of the work?

Yes. FactoryTalk View ME, the software for PanelView Plus terminals, and FactoryTalk View SE. During a PLC-5 or SLC 500 migration, PanelView Standard and older HMIs move to FactoryTalk View ME or SE. Field note: when to stop using ME. Moving to Ignition instead? See Ignition programming.

What should I send with an Allen-Bradley RFQ?

The ACD or RSS file, the symptom, and your outage window. Upload it with the form on this page and it goes straight to sales@ts-controls.com. Line down? Call (877) 790-4697, 24/7, subject to personnel availability.

Send the ACD or RSS file.

Line down? (877) 790-4697 24/7, subject to personnel availability

What to send

  • STEP 5: the whole project folder, zipped (the program file ends in ST.S5D, plus the other S5D files beside it).
  • STEP 7 V5.x: a SIMATIC Manager archive (.zip), from File > Archive.
  • TIA Portal: a project archive (.zapNN) from Project > Archive, and the TIA Portal version and update level.
  • RSLogix 5 and 500: the program file (.RSP or .RSS), saved from the software or uploaded from the PLC first.
  • Studio 5000: the project (.ACD) or an .L5X export, and the controller firmware revision.
  • Robot backups: a full KUKA archive, a FANUC “All of above” backup or an ABB controller backup.

Which files to include, by platform
